Siemens SINAMICS V20 Series User Manual

Parameter list
7.2 Parameter list
SINAMICS V20 Inverter
154 Operating Instructions, 07/2012, A5E03728167
Parameter Function Range Factory
default
Can be
changed
Scaling Data
set
Data
type
Acc.
Level
Note: See P0844
P0848[0...2] BI: 1. OFF3 - 1 T - CDS U32 /
Bin
3
Defines first source of OFF3 when P0719 = 0 (BICO).
Dependency: If one of the digital inputs is selected for OFF3, the inverter will not run unless the digital input is active.
Note: OFF3 means quick ramp-down to 0.
OFF3 is low-active, i.e.
0 = Quick ramp-down.
1 = Operating condition.
P0849[0...2] BI: 2. OFF3 - 1 T - CDS U32 /
Bin
3
Defines second source of OFF3.
Dependency: In contrast to P0848 (first source of OFF3), this parameter is always active, independent of P0719
(selection of command and frequency setpoint). See P0848.
Note: See P0848
P0852[0...2] BI: Pulse enable - 1 T - CDS U32 /
Bin
3
Defines source of pulse enable / disable signal.
Dependency: Active only when P0719 = 0 (Auto selection of command / setpoint source).
P0881[0...2] BI: Quick stop source 1 - 1 T - CDS U32 /
Bin
3
Allows quick stop source 1 command to be selected using BICO. The signal is expected to be active low
(default setting P0886 = 2).
P0882[0...2] BI: Quick stop source 2 - 1 T - CDS U32 /
Bin
3
Allows quick stop source 2 command to be selected using BICO. The signal is expected to be active low
(default setting P0886 = 2).
P0883[0...2] BI: Quick stop override - 0 T - CDS U32 /
Bin
3
Allows quick stop override command source to be selected using BICO. The signal is expected to be
active high.
r0885.0...4 CO / BO: Quick stop
status
- - - - - U16 3
Bit field describing status of quick stop.
Bit Signal name 1 signal 0 signal
00 Quick stop is active Yes No
01 Quick stop selected Yes No
02 Override selected Yes No
04 Quick stop enabled Yes No
P0886[0...2] Quick stop input type 0 - 4 2 T - CDS U16 3
Control Word for selecting the quick stop input type.
0 Quick stop not selected
1 Quick stop input active high
2 Quick stop input active low
3 Quick stop input positive edge triggered
4 Quick stop input negative edge triggered
