Parameter list
7.2 Parameter list
SINAMICS V20 Inverter
Operating Instructions, 07/2012, A5E03728167
161
Parameter Function Range Factory
default
Can be
changed
Scaling Data
set
Data
type
Acc.
Level
P1013[0...2] Fixed frequency 13 [Hz] -599.00 -
599.00
0.00 U, T - DDS Float 2
Defines fixed frequency setpoint 13.
Note: See P1001
P1014[0...2] Fixed frequency 14 [Hz] -599.00 -
599.00
0.00 U, T - DDS Float 2
Defines fixed frequency setpoint 14.
Note: See P1001
P1015[0...2] Fixed frequency 15 [Hz] -599.00 -
599.00
0.00 U, T - DDS Float 2
Defines fixed frequency setpoint 15.
Note: See P1001
P1016[0...2] Fixed frequency mode 1 - 2 1 T - DDS U16 2
Fixed frequencies can be selected in two different modes. P1016 defines the mode.
1 Direct selection
2 Binary selection
Note: See P1001 for description of how to use fixed frequencies.
P1020[0...2] BI: Fixed frequency
selection Bit 0
- 722.3 T - CDS U32 /
Bin
3
Defines origin of fixed frequency selection.
Dependency: Accessible only if P0701 - P070x = 99 (function of digital inputs = BICO)
P1021[0...2] BI: Fixed frequency
selection Bit 1
- 722.4 T - CDS U32 /
Bin
3
See P1020
P1022[0...2] BI: Fixed frequency
selection Bit 2
- 722.5 T - CDS U32 /
Bin
3
See P1020
P1023[0...2] BI: Fixed frequency
selection Bit 3
- 722.6 T - CDS U32 /
Bin
3
See P1020
r1024 CO: Actual fixed
frequency [Hz]
- - - - - Float 3
Displays sum total of selected fixed frequencies.
r1025.0 BO: Fixed frequency
status
- - - - - U16 3
Displays the status of fixed frequencies.
Bit Signal name 1 signal 0 signal
00 Status of FF Yes No
P1031[0...2] MOP mode - 1 U, T - DDS U16 2
MOP mode specification.
Bit Signal name 1 signal 0 signal
00 Setpoint store active Yes No
01 No On-state for MOP necessary Yes No
Note: Defines the operation mode of the motorized potentiometer. See P1040.
