Page #198 background image
Parameter list
7.2 Parameter list
SINAMICS V20 Inverter
198 Operating Instructions, 07/2012, A5E03728167
Parameter Function Range Factory
default
Can be
changed
Scaling Data
set
Data
type
Acc.
Level
P2186[0...2] Lower torque threshold 1
[Nm]
0.0 -
99999.0
0.0 U, T - DDS Float 3
Lower limit threshold value 1 for comparing actual torque.
Dependency: See P2181 for calculated default value.
P2187[0...2] Upper torque threshold 2
[Nm]
0.0 -
99999.0
Value in
r0333
U, T - DDS Float 3
Upper limit threshold value 2 for comparing actual torque.
Dependency: This parameter is influenced by automatic calculations defined by P0340.
See P2181 for calculated default value.
Note: See P2185
P2188[0...2] Lower torque threshold 2
[Nm]
0.0 -
99999.0
0.0 U, T - DDS Float 3
Lower limit threshold value 2 for comparing actual torque.
Dependency: See P2181 for calculated default value.
P2189[0...2] Upper torque threshold 3
[Nm]
0.0 -
99999.0
Value in
r0333
U, T - DDS Float 3
Upper limit threshold value 3 for comparing actual torque.
Dependency: This parameter is influenced by automatic calculations defined by P0340.
See P2181 for calculated default value.
Note: See P2185
P2190[0...2] Lower torque threshold 3
[Nm]
0.0 -
99999.0
0.0 U, T - DDS Float 3
Lower limit threshold value 3 for comparing actual torque.
Dependency: See P2181 for calculated default value.
P2192[0...2] Time delay for belt
failure [s]
0 - 65 10 U, T - DDS Float 3
P2192 defines a delay before warning / trip becomes active.
- It is used to eliminate events caused by transient conditions.
- It is used for both methods of fault detection.
r2197.0...12 CO / BO: Monitoring
word 1
- - - - - U16 3
Monitoring word 1 which indicates the state of monitor functions. Each bit represents one monitor function.
Bit Signal name 1 signal 0 signal
00 |f_act| <= P1080 (f_min) Yes No
01 |f_act| <= P2155 (f_1) Yes No
02 |f_act| > P2155 (f_1) Yes No
03 f_act >= zero Yes No
04 f_act >= setp. (f_set) Yes No
05 |f_act| <= P2167 (f_off) Yes No
06 |f_act| >= P1082 (f_max) Yes No
07 f_act == setp. (f_set) Yes No
08 Act. current |r0027| >= P2170 Yes No
09 Act. unfilt. Vdc < P2172 Yes No
10 Act. unfilt. Vdc > P2172 Yes No
11 Load missing Yes No
12 |f_act| > P1082 with delay Yes No
