Siemens SINAMICS V20 Series User Manual

Parameter list
7.2 Parameter list
SINAMICS V20 Inverter
224 Operating Instructions, 07/2012, A5E03728167
Parameter Function Range Factory
default
Can be
changed
Scaling Data
set
Data
type
Acc.
Level
Index: See P2869
Dependency: P2802[13] assigns the Comparator to the processing sequence.
r2888.0 BO: CMP 2 - - - - - U16 3
Displays result bit of Comparator 2. See r2811 for the bit field description.
Dependency: See P2887
P2889 CO: Fixed setpoint 1 in
[%]
-200.00 -
200.00
0.00 U, T - - Float 3
Fixed percent setting 1.
P2889
P2890
-200% ... 200%
&RQQHFWRU6HWWLQJLQ
5DQJH
P2890 CO: Fixed setpoint 2 in
[%]
-200.00 -
200.00
0.00 U, T - - Float 3
Fixed percent setting 2.
P2940 BI: Release wobble
function
- 0.0 T - - U32 2
Defines the source to release the wobble function.
P2945 Wobble signal frequency
[Hz]
0.001 -
10.000
1.000 T - - DECU
16
2
Sets the frequency of the wobble signal.
P2946 Wobble signal amplitude
[%]
0.000 -
0.200
0.000 T - - DECU
16
2
Sets the value for the amplitude of the wobble-signal as a proportion of the present ramp function
generator (RFG) output. The value of P2946 is multiplied by the output value of the RFG then added to
RFG output.
For example, if the RFG output is 10 Hz, and P2946 has a value of 0.100, the wobble signal amplitude will
be 0.100 * 10 = 1 Hz. This means that the RFG output will therefore wobble between 9 Hz and 11 Hz.
P2947 Wobble signal
decrement step
0.000 -
1.000
0.000 T - - DECU
16
2
Sets the value for decrement step at the end of the positive signal period. The amplitude of the step is
dependant upon the signal amplitude as follows:
Amplitude of signal decrement step = P2947 * P2946
P2948 Wobble signal increment
step
0.000 -
1.000
0.000 T - - DECU
16
2
Sets the value for the increment step at the end of the negative signal period. The amplitude of the
increment step is dependant upon the signal amplitude as follows:
Amplitude of signal increment step = P2948 * P2946
P2949 Wobble signal pulse
width [%]
0 - 100 50 T - - U16 2
Sets the relative widths of the rising and falling pulses. The value in P2949 sets the proportion of the
wobble period (determined by P2945) allocated to the rising pulse, the remainder of the time is allocation
to the falling pulse.
A value of 60% in P2949 means that 60% of the wobble period the wobble output will be rising. For the
remaining 40% of the wobble period the wobble output will be falling.
r2955 CO: Wobble signal
output [%]
- - - - - DECI
32
2
Displays the output of the wobble function.
