Siemens SINAMICS V20 Series User Manual

Commissioning
5.1 The built-in Basic Operator Panel (BOP)
SINAMICS V20 Inverter
30 Operating Instructions, 07/2012, A5E03728167
Multi-function button
Short press ( < 2 s)
• Enters the parameter setting menu or moves to the next screen
• Restarts the digit by digit editing on the selected item
• If pressed twice in digit by digit editing, returns to the previous screen
without changing the item being edited
M
M
Long press ( > 2 s)
• Returns to the status screen
• Enters the setup menu
Short press ( < 2 s)
• Switches between status values
• Enters edit value mode or change to the next digit
• Clears faults
OK
OK
Long press ( > 2 s)
• Quick parameter number or value edit
M
M
+
OK
OK
Hand / Jog / Auto
Press to switch between different modes:
M
M
OK
OK

M
M
OK
OK

M
M
OK
OK

(No icon)
(With hand icon)
(With flashing hand icon)
Auto mode
Hand mode
Jog mode
Note:
Jog mode is only available if the motor is stopped.
• When navigating a menu, it moves the selection up through the screens available.
• When editing a parameter value, it increases the displayed value.
• When the inverter is in RUN mode, it increases the speed.
• Long press (> 2 s) of the key quickly scrolls up through parameter numbers, indices, or values.
• When navigating a menu, it moves the selection down through the screens available.
• When editing a parameter value, it decreases the displayed value.
• When the inverter is in RUN mode, it decreases the speed.
• Long press (> 2 s) of the key quickly scrolls down through parameter numbers, indices, or values.
+
Reverses the direction of rotation of the motor. Pressing the two keys once activates reverse motor
rotation. Pressing the two keys once again deactivates reverse rotation of the motor. The reserve icon (
) on the display indicates that the output speed is opposite to the setpoint.
Inverter status icons
Inverter has at least one pending fault.
Inverter has at least one pending alarm.
: Inverter is running (motor frequency may be 0 rpm).
(flashing): Inverter may be energized unexpectedly (for example, in frost protection
mode).
Motor rotates in the reversed direction.
: Inverter is in HAND mode.
(flashing): Inverter is in JOG mode.
