2 Solution
2.2 Hardware and Software Components
Speed Control with SINAMICS V90 and S7-1200 via PROFINET
Entry-ID: 109739222, V1.0, 07/2016
6
 Siemens AG 2016 All rights reserved
2.2 Hardware and Software Components
2.2.1 Validity
This application example is valid for
 TIA Portal V13 or newer
 S7-1200 CPU with PN interface
 SINAMICS V90 PN FW V10000.4 or newer
 SIMOTICS S-1FL6 Li motor
2.2.2 Used Components
The application was generated with the following components:
Hardware components
Table 2-1
Component
No.
Article number
Note
SIMATIC S7-1200 1214C
DC/DC/DC
1
6ES7214-1AG31-0XB0
SINAMICS V90 PN 200V
1
6SL3210-5FB10-2UF0
200W
SIMOTICS S-1FL6 Li motor
1
1FL6032-2AF21-1AA1
200W
Standard software components
Table 2-2
Component
No.
Article number
Note
TIA Portal
1
V13
SINAMICS V-ASSISTANT
1
V1.04.00.02
Sample files and projects
The following list includes all files and projects that are used in this example.
Table 2-3
Component
Note
109739222_SpeedControl_V90_S7-1200_MOVE_PROJ.pdf
Project file for
Scenario A
109739222_SpeedControl_V90_S7-1200_SINA_SPEED_PROJ.zip
Project file for
Scenario B
109739222_SpeedControl_V90_S7-1500_DOC_en.pdf
Documentation
