Technical Appendix
6-10
SINUMERIK 802S base line
Start-Up
34020 REFP_VELO_SEARCH_CAM
mm/min,
rev/min
Reference point approach velocity RESET
_always 5000.0 0.0 plus DOUBLE 2/7
34030 REFP_MAX_CAM_DIST
mm,
deg.
Maximum distance to reference cam RESET
_always 10000.0 0.0 plus DOUBLE 2/7
34040 REFP_VELO_SEARCH_MARKER
mm/min,
rev/min
Creep speed (encoder no.) RESET
_always 300.0 0.0 plus DOUBLE 2/7
34050 REFP_SEARCH_MARKER_REVERSE
– Direction reversal to reference cams (encoder no.) RESET
_always 0 *** ***
BOOLEAN
2/7
34060 REFP_MAX_MARKER_DIST
mm, Maximum distance to reference mark. Max. distance to 2
reference marks
for distance–coded measuring systems.
RESET
_always 20.0 0.0 plus DOUBLE 2/7
34070 REFP_VELO_POS
mm/min,
rev/min
Reference point positioning velocity RESET
_always 1000.0 0.0 plus DOUBLE 2/7
34080 REFP_MOVE_DIST
mm,
deg.
Reference point distance/target point for distance–coded
system
RESET
_always –2.0 – – DOUBLE 2/7
34090 REFP_MOVE_DIST_CORR
mm,
deg.
Reference point offset/absolute offset distance–coded POWER ON
_always 0.0 – – DOUBLE 2/7
34092 REFP_CAM_SHIFT
mm,
deg.
Electr. cam offset of incremental measuring systems with
equidistant zero marks
RESET
_always 0.0 0.0 plus DOUBLE 2/7
