Siemens SINUMERIK 808D Commissioning Manual

Commissioning Manual
01/2017
329
Tag identifier
Meaning
SEND_MESSAGE
The tag sends a message with two parameters to the active form, which is processed in the
tag message (see also MESSAGE).
Syntax:
<SEND_MESSAGE>p1, p2</SEND_MESSAGE>
Example:
<LET name="user_selection" />
<SOFTKEY POSITION="3">
<CAPTION>Set%nParameter</CAPTION>
<SEND_MESSAGE>1, 10</SEND_MESSAGE>
</SOFTKEY>
…
…
<FORM>
…
…
<MESSAGE>
<SWITCH>
<CONDITION>$message_par1</CONDITION>
<CASE value="1">
<OP> user_selection = $message_par2 </OP>
…
</CASE>
</SWITCH>
</MESSAGE>
…
…
</FORM>
FOCUS_IN
Dialog box message
The tag is called if the system places the focus on a control. To identify the control, the sys-
tem copies the name of the control into variable
$focus_name
and the value of the attribute
item_data
into variable
$focus_item_data
.
This message can be used, for example, to output images depending on the focus position.
Example:
<focus_in>
<PRINT text="focus on filed:%s, %d">$focus_name,
$focus_item_data </PRINT>
</focus_in>
PAINT
Dialog box message
The tag is executed when the dialog box is displayed. All the texts and images which are to
be displayed in the dialog box should be specified here.
Further, the tag is executed if the system identifies that parts of the dialog box are to be
redisplayed. For example, this can be initiated by closing high-level windows.
TIMER
Dialog box message
The tag is executed cyclically.
Each form is assigned a timer. The tag is executed within a period less than 100 ms.
