Programming principles
1.1 Fundamentals of programming
Turning Part 2: Programming (Siemens instructions)
16 Programming and Operating Manual, 05/2012, 6FC5398-5DP10-0BA0
Address Significance Value assignments Information Programming
H
H0=
to
H9999=
H function ± 0.0000001 ...
9999 9999
(8 decimal places) or
specified as an
exponent:
± (10-300 ... 10+300 )
Value transfer to the PLC;
significance defined by the
machine manufacturer
H0=... H9999=...
e.g.: H7=23.456
I Interpolation
parameters
±0.001 ... 99 999.999
Thread:
0.001 ... 2000.000
Belongs to the X axis; meaning
dependent on G2,G3 ->circle
center or
G33, G34, G35 G331, G332 ->
thread lead
See G2, G3 and G33,
G34, G35
K Interpolation
parameters
±0.001 ... 99 999.999
Thread:
0.001 ... 2000.000
Belongs to the Z axis; otherwise,
as with I
See G2, G3 and G33,
G34, G35
I1= Intermediate point
for circular
interpolation
±0.001 ... 99 999.999 Belongs to the X axis;
specification for circular
interpolation with CIP
See CIP
K1= Intermediate point
for circular
interpolation
±0.001 ... 99 999.999 Belongs to the Z axis;
specification for circular
interpolation with CIP
See CIP
L Subroutine; name
and call
7 decimals;
integer only, no sign
Instead of a free name, it is also
possible to select L1
...L9999999;
this also calls the subroutine
(UP) in a separate block,
Please note: L0001 is not
always equal to L1.
The name "LL6" is reserved for
the tool change subroutine.
L.... ;separate block
M Additional function 0 ... 99
only integer, no sign
For example, for initiating
switching actions,
such as "coolant ON",
maximum five M functions per
block.
M...
M0 Programmed stop The machining is stopped at the
end of a block containing M0; to
continue, press NC START.
M1 Optional stop As with M0, but the stop is only
performed if a special signal
(Program control: "M01") is
present.
M2 End of main program with return to
beginning of program
Can be found in the last block of
the processing sequence
M30 End of program (as M2) Can be found in the last block of
the processing sequence
M17 End of subroutine Can be found in the last block of
the processing sequence
M3 CW rotation of spindle
M4 CCW rotation of spindle
M5 Spindle stop
