Programming principles
1.1 Fundamentals of programming
Turning Part 2: Programming (Siemens instructions)
Programming and Operating Manual, 05/2012, 6FC5398-5DP10-0BA0
15
Address Significance Value assignments Information Programming
G53 Non-modal skipping of the settable work
offset
9: Suppressing the settable work
offset
non-modal
G153 Non-modal skipping of the settable work
offset including base frame
G60 * Exact stop
G64 Continuous-path mode
10: Approach behavior
modally effective
G62 Corner deceleration at inside corners when
tool radius offset is active (G41, G42)
Only in conjunction with
continuous-path mode.
G62 Z... G1
G9 Non-modal exact stop 11: Non-modal exact stop
non-modal
G601 * Exact stop window, fine, with G60, G9
G602 Exact stop window, coarse, with G60, G9
12: Exact stop window
modally effective
G621 Corner deceleration at all corners Only in conjunction with
continuous-path mode.
G621 AIDS=...
G70 Inch dimension input
G71 * Metric dimension data input
13: Inch/metric dimension data
modally effective
G700 Inch dimension data input; also for feedrate
F
G710 Metric dimension data input; also for
feedrate F
G90 * Absolute dimension data input
G91 Incremental dimension input
14: Absolute / incremental
dimension
modally effective
G94 Feed F in mm/min
G95 * Feedrate F in mm/spindle revolutions
G96 Constant cutting rate ON
(F in mm/rev., S in m/min)
G96 S... LIMS=... F...
G97 Constant cutting speed OFF
15: Feedrate / spindle
modally effective
G450 * Transition circle
G451 Point of intersection
18: Behavior at corners when
working with tool radius
compensation
modally effective
BRISK * Jerking path acceleration
SOFT Jerk-limited path acceleration
21: Acceleration profile
modally effective
FFWOF * Feedforward control OFF
FFWON Feedforward control ON
24: Feedforward control
modally effective
DIAMOF Radius dimensioning
DIAMON * Diameter dimensioning
29: Dimension Radius / diameter
modally effective
G290 * SIEMENS mode
G291 External mode
47: External NC languages
modally effective
