Siemens SINUMERIK 808D Programming And Operating Manual

Typical turning program
Turning Part 2: Programming (Siemens instructions)
Programming and Operating Manual, 05/2012, 6FC5398-5DP10-0BA0
205
;#7__DlgK contour definition begin - Don't change!;*GP*;*RO*;*HD*
N160 G18 G90 DIAMON;*GP*
N170 G0 Z0 X27 ;*GP*
N180 G1 Z-.89 X24.11 ;*GP*
N190 Z-9 X16 ;*GP*
N200 Z-21 ;*GP*
N210 X10 ;*GP*
;CON,V64,2,0.0000,4,4,MST:1,2,AX:Z,X,K,I;*GP*;*RO*;*HD*
;S,EX:0,EY:27,ASE:0;*GP*;*RO*;*HD*
;LA,EX:-.89,EY:24.11;*GP*;*RO*;*HD*
;LA,DEX:-8.11,EY:16;*GP*;*RO*;*HD*
;LL,EX:-21;*GP*;*RO*;*HD*
;LD,EY:10;*GP*;*RO*;*HD*
;#End contour definition end - Don't change!;*GP*;*RO*;*HD*
CON1_E:;************* CONTOUR ENDS ************
