11.90 3 Operating Sequences
3.1.11 Contour
Call desired program using
”SELECT PROGRAM”.
Operate the ”GUIDING” softkey.
Operate the ”BLOCK NUMBER” softkey. The control
generates the lowest available block number N... .
SELECT
PROGRAM
GUIDING
BLOCK
NUMBER
Enter the functions for feed F... and
spindle S... using the numerical keys and
store them using the input key.
Select the ”CONTOUR” softkey.
