4 Monitoring Functions 09.91
4.6 Listing of the alarms/alarm description
Alarm No.
Alarm Text:
22
”Time monitoring RS232C (V.24)”
Reason:
Remedy:
Delay of 60 sec. for data transfer exceeded
– Check external device
– Check cable
– Check setting data 5017 and 5025
– Set bit 0 to ”1”.
Alarm No.
Alarm Text:
23
”Char. parity error RS232C (V.24)”
Reason:
Effect:
Remedy:
Explanation:
Punched tape dirty or damaged
– RS232C (V.24) transfer is interrupted
– the last block is not stored
With block transfer: faulty cable
– RS232C (V.24) transfer is stopped
Check punched tape
With block transfer: Check connection
Depending upon the definition of the start of program ”%” or ”EOR”,
the NC automatically establishes the ISO or EIA code upon receipt of
this character, and establishes the character parity.
With block transfer: Each character of a data block is checked for
character parity and the block itself for BCC.
When checking the characters or the block, it was established that one
character did not have the set parity.
Remarks: Do not switch off control, data may be lost.
Alarm No.
Alarm Text:
24
”Invalid EIA character RS232C (V.24)”
Reason:
Effect:
Remedy:
Explanation:
An EIA character with the correct parity was read in, but the character
was not defined in EIA code
– Data transfer is interrupted
– The last block is invalid
check punched tape:
Setting data 5026 (EIA code for ”@”) and
Setting data 5027 (EIA code for ”:”)
The ”=” character in EIA code is not defined, and the following data
cannot be read in:
%TEA1 (NC machine data)
%TEA2 (PLC machine data)
%TEA5 (Drive machine data for SERCOS interface)
%TEA6 (Drive machine data for parallel interface)
%RPA (R parameters)
%ZOA (Zero offsets)
%TOA (Tool offsets)
%PCA (PLC Alarm text)
Main programs and subroutines with R parameter calculations
4-8
© Siemens AG 1990 All Rights Reserved 6ZB5 410-0EP02
SINUMERIK 810T, GA3 (BN)
