4 Monitoring Functions 01.93
4.6 Listing of the alarms/alarm description
Alarm No.
Alarm Text:
3004
”CL800 Error”
Reason:
Remedy:
– @ Function not implemented
– Incorrect address after the @
– Incorrect number of addresses after the @
– Value in K, R or P not permissible
– Number of decades too large
– No decimal point permissible
– Jump destination incorrectly defined
– System line (NC MD, PLC MD, TO ...) does not exist
– Bit number too large
– Incorrect angle data for sine or cosine
– Program as @ list
– Only K, R and P are valid addresses
– Define jump destination forward with ”+”, back with ”-”
– Check validity of data in given addresses
– Select decoded single block (DEC-SBL) and check program again
Alarm No.
Alarm Text:
3005
”Contour definition error”
Reason:
Remedy:
The coordinates in the contour description have been defined so that
no intersection point is given.
As for alarm 3000
Alarm No.
Alarm Text:
3006
”Wrong block structure”
Reason:
Remedy:
– More than 3 M functions have been programmed in one block
– More than 1 S function has been programmed in one block
– More than 1 T function has been programmed in one block
– More than 1 H function has been programmed in one block
– More than 4 auxiliary functions have been program. in one block
– More than 3 axes with G00/G01 have been program. in one block
– More than 2 axes with G02/G03 have been program. in one block
– G04 has been programmed with addresses other than ”X” or ”F”
– M19 has been programmed with addresses other than ”S”
– Invalid, or no interpolation parameters with G02/G03
– G92 P.. not in a block of its own
– G74 not in a block of its own.
– At least one axis and no rotary axes or more than 2 rotary axes are
programmed in a block with active G98 or G36.
– Radius, angle or L or P are programmed in a block with active G36.
– Because of the thread lead and the distance to go of the infeed
axis, the distance to go with G36 for the rotary axis is too large.
– G98 is active, but neither G0, G1 or G36 of G group 0 is active.
– The function TRANSMIT is active for the same rotary axis in a block
with G98 or G36.
– The rotary axis in a block with active G98 or G36 is also selected as
a rotary axis for cylindrical interpolation.
– Contour definition is traversed with G98 feed.
– In a block with active G36 the thread lead is either missing or is not
assigned to the programmed infeed axis.
– An axis switchover command (spindle/rotary axis) is not
programmed alone in a block.
As for alarm 3000 (with axis switchover only possible with RESET)
4-26
© Siemens AG 1990 All Rights Reserved 6ZB5 410-0EP02
SINUMERIK 810T, GA3 (BN)
