01.93 4 Monitoring Functions
4.6 Listing of the alarms/alarm description
Alarm No.
Alarm Text:
3007
”Wrong setting data program”
Reason:
Remedy:
– G25/G26 has been programmed
– G92 has been programmed with an address other than ”S” or ”P”
– M19 has been programmed with an address other than ”S”
As for alarm 3000
Alarm No.
Alarm Text:
3008
”Subroutine error”
Reason:
Remedy:
– Subroutine call without pass count ”P”
– M30 has been programmed as end of program
– M17 missing at end of program
– 5 levels of nesting have been called
– M17 has been programmed in a main program
As for alarm 3000
Alarm No.
Alarm Text:
3009
”Program disabled”
Explanation: – L0 preselected in the AUTOMATIC display (not permitted).
– Missing program called by PLC.
Alarm No.
Alarm Text:
3010
”Intersection error”
Reason:
Remedy:
This error can appear in conjunction with the L95 stock removal cycle,
when:
– A contouring program has been programmed without G00, G01,
G02, G03
– @ 714 has been programmed in a contouring program
– An incorrect plane has been selected in a contouring program
– No intersection point has been found
– More than a quarter circle has been programmed in a contouring
program
As for alarm 3000
Alarm No.
Alarm Text:
3011
”Too many axes/axes twice”
Reason:
Remedy:
– An axis has been programmed twice in the same block
– More axes have been programmed than present on the machine
As for alarm 3000
© Siemens AG 1990 All Rights Reserved 6ZB5 410-0EP02 4-27
SINUMERIK 810T, GA3 (BN)
