1 Introduction 10.91
1.9.2 Logging via CP315 with the SINUMERIK 840/880
Part 5
( @A*13*1 @------@ @-------------@ @-------------@ @-------------@
@-------------@ @-------------@ @---------@ )
( @M*15*8 )
( @O*64** )
( @R*14*1 @I @ @ I @ @ I @ @ I @
@ I I @ @ I @ @ I@ )
( @T*0*16 @R206*F8.3 )
( @T*0*28 @R209*F8.3 )
( @T*0*40 @R200*F5.3 )
( @T*0*49 @R203*F5.3 )
( @T*0*58 @R212*F5.3 )
( @Z*0*69 )
( @T*1*16 @R207*F8.3 ) The supplementary lines need not
( @T*1*28.@R210*F8.3 ) be defined for this example.
( @T*1*40 @R201*F5.3 )
( @T*1*49 @R204*F5.3 )
( @T*1*58 @R213*F5.3 )
( @Z*1*69 )
( @T*2*16 @R208*F8.3 )
( @T*2*28 @R211*F8.3 )
( @T*2*40 @R202*F5.3 )
( @T*2*49 @R205*F5.3 )
( @T*2*58 @R214*F5.3 )
( @Z*2*69 )
( @E )
M30
Part 3
Part 4
–
Programming of initiation triggering transfer of the part program to the PLC
%MPF 201
N1 R39=00000000 (Define control parameter)
N2 R1=200 (Specify MPF No.)
N3 L988 (Initiate transfer)
N4 M30
– Programming of part program for workpiece measurement
%MPF 202
N1 R900=R900+1
R39=00000100
R40=R900
R41=12343210
R43=974
R44=10002000
N4 L988
N5 G54 G00 X260 Z T1 D31
N10 R22=1 R23=22 R25=0
R27=1 R28=1 R30=1
N15 R31=1 R32=-20 R33=0 R36=1
N20 L973
N25 R30=2 R32=240
N30 L973
N35 G54 G00 Z40 T2 D32
N40 R10=8 R11=0 R22=1
R23=21 R25=0 R27=1
R28=1 R29=1 R30=2
N45 R33=0.002 R34=0.005
R36=2 R37=1 R40=0.3
R41=-0.3 R42=200
N46 R39=11110220
N55 L974
(Increment workpiece counter by 1)
(Define control parameter for header data transfer)
(Header data)
(Header data)
(Header data)
(Header data)
(Transfer header data to the PLC)
(Select ZO, call T No. and TO No.)
(Define parameter for calibration)
(Calibrate probe in minus Z direction)
(Define parameter for calibration)
(Calibrate probe in minus X direction)
(Position MP1, call T No. and MC No.)
(Define parameter for measurement)
(Define control parameter for transfer of measurement
results)
(Measure MP1)
1–42 © Siemens AG 1990 All Rights Reserved 6FC5197- AB70
SINUMERIK 840/850/880 (BN)
