10.91 1 Introduction
1.9.2 Logging via CP315 with the SINUMERIK 840/880
N60 G00 Z70 T1 D31
N65 X175
N70 R10=9 R30=1
R40=0.2
R41=-0.2 R42=50
N71 R39=11110220
N80 L974
N85 G00 Z80 T2 D32
N90 R10=10 R30=2
R40=0.5
R41=-0.5 R42=150
N91 R39=11110220
N100 L974
N105 G00 Z150 T1 D31
N110 X50
N115 R10=11 R30=1
R40=0.3
R41=-0.3 R42=100
N116 R39=11110220
N125 L974
N130 G53 G00 Z250 T0
N135 G53 X280
N140 R39=11911311
N145 L988
N150 M30
(Position probe to face MP2)
(Define parameter for measurement)
(Define control parameter for transfer of measurement results)
(Measure MP2)
(Position probe to face MP3)
(Define parameter for measurement)
(Define control parameter for transfer of measurement results)
(Measure MP3)
(Position probe to face MP4)
(Define parameter for measurement)
(Define control parameter for transfer of measurement results)
(Measure MP4)
(Retract Z axis)
(Retract X axis)
(Define end of protocol)
(and transfer to the PLC)
– Log of programming example
Part number . . . . . . . . . . : 17 Date: 30.08.91 Page: 1
Order number . . . . . . . . : 12343210
Program number . . . . . . : 974 Serial number . . . . . . : 10002000
Measuring
point
Setpoint
Actual
value
Tolerance limit
+–
Setpoint
difference
Time of
day
1 200.000 200.104 0.300 – 0.300 – 0.104 09:36:20
2 50.000 50.797 0.200 – 0.200 –0.797 * 09:36:30
3 150.000 149.946 0.500 – 0.500 0.054 09:36:40
4 100.000 100.141 0.300 – 0.300 – 0.141 09:36:50
© Siemens AG 1990 All Rights Reserved 6FC5197- AB70 1–43
SINUMERIK 840/850/880 (BN)
