Siemens SINUMERIK 840C User Manual

4 Measuring Cycles for Turning Machines 08.96
4.1.3 L972/L982 Automatic tool measurement
The following parameters must be defined prior to call:
Parameters Description
R11 = 0
> 0
Without empirical value
Empirical value memory number m
R13 Angular offset (with R23 102)
R18 = 0
0
Change position X axis (from MDC) (with reference to machine zero)
Variable change position X axis (with reference to trigger points tool
probe)
R19 = 0
0
Change position Z axis (from MDC) (with reference to machine zero)
Variable change position Z axis (with reference to trigger points tool
probe)
R22 Tool probe No.
R23 Measurement variant
xxx 02
xxx 12
xxx 22
R25
R25=0
Variable measuring speed in mm/min
Standard cycle value
R26 Starting angle (with tool type 26)
R27 = 1...R
max
Number of measurements at same location (typically 1..3)
R28 = 1...R
max
Multiplication factor for measurement path ”2a”
R33 Zero offset range
R36 Safe area
see Section 2.7.1
4–18 ©
Siemens AG 1990 All Rights Reserved 6FC5197- AB70
SINUMERIK 840/850/880 (BN)
