Parameter Description Unit
Machining
● ∇ (roughing)
● ∇∇ (semi-finishing)
● ∇∇∇ (finishing)
● Deselection
Mold-making
function
● Advanced Surface
● Top Surface
Note
The field can be hidden.
Please observe the information provided by the machine manufacturer.
Contour tolerance
● Input of the maximum allowance from the programmed contour.
● Standard default values depending on the type of machining via the "Default
values" softkey:
– ∇ (roughing) 0.100
– ∇∇ (pre-finishing) 0.050
– ∇∇∇ (finishing) 0.010
Note
The default values may have been changed by the manufacturer.
Please observe the information provided by the machine manufacturer.
Smoothing (not
for "Advanced
Surface")
● Yes
Optimized path within the contour tolerance
● No
Path close to contour
Note
The field can be hidden.
Please observe the information provided by the machine manufacturer.
Multi-axis
program
Multi-axis program for 5-axis machines
● Yes
The orientation tolerance > 0 degrees can be entered here
● No
The value 1 is entered automatically
Note
The field can be hidden.
Please observe the information provided by the machine manufacturer.
ORI tolerance Specification of the maximum allowance from the programmed tool orientation (for 5-
axis machines).
Programming technological functions (cycles)
10.6 Further cycles and functions
Milling
650 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
