Note
Referenced axes
The positions of the axes in the machine area must be known so that the protection areas can
be monitored. For this reason, collision avoidance is only active after the referencing.
NOTICE
No complete machine protection
Incomplete models, e.g. machine parts, workpieces that have not been modeled or new
objects in the working area, are not monitored and can therefore cause collisions.
References
More detailed explanations of collision avoidance can be found in the following reference:
Special Functions Function Manual:
● Section: "Kinematic chain (K7)"
● Section: "Geometric machine modeling (K8)"
● Section: "Collision avoidance, internal (K9)"
● Section: "Collision avoidance, external (K11)"
Collision avoidance
Milling
680 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
