10.Align the positioner/mount at the center of the actuator.
11.Tighten the positioner/mount unit.

Figure 4-11 Positioner with mount attached to the part-turn actuator
Installing/mounting
4.3 Mounting to part-turn actuator
SIPART PS100
Compact Operating Instructions, 05/2021, A5E50188940-AA 23
