Configuration
z Highlight the box beside Field Detect. Pressing the button toggles between
On and Off. When set to On, the Field Detection helps prevent shaking in the
Simplex mode. It does this by recording odd numbered fields from odd
numbered cameras and even numbered fields from even numbered cameras.
z Highlight the first box beside Auto Deletion. Pressing the button toggles
between On and Off. When set to On, the DVR will delete video recorded prior
to the user-defined period. Highlight the second box beside Auto Deletion and
press the
button to select the length of time recorded data will be kept (from 1
to 99 days).
z You can save your changes by highlighting OK and pressing the
button
.
Selecting Cancel exits the screen without saving the changes.
3.7.2 Time-Lapse Record Mode Setup Screen
Fig. 45 Time-Lapse Record Setup screen.
z Highlight the box under Speed and press the button. A drop-down list of
record speeds appears. You can select from 1 image per 10 seconds to 50
images per second for PAL (to 60 images per second NTSC).
NOTE:
If you have set the Record Resolution for High, you will not be able to select 50 ips PAL (60 ips
NTSC).
44
Siemens Building Technologies SISTORE AX9 AX16_EN.doc
Fire & Security Products 09.2004
