Operation
4.6.2 Date/Time Search
Fig. 77 Date/Time Search screen.
z Move the cursor over the date and press the button. You can use the Left
and Right arrow buttons to highlight the year, month and day. Use the Up and
Down arrow buttons to change to the date you want to search for. Once you
have set the date you want, press the
button.
z Move the cursor over the time and press the button. You can use the Left
and Right arrow buttons to highlight the hour, minutes and seconds. Use the Up
and Down arrow buttons to change to the time you want to search for. Once you
have entered the time you want, press the
button.
z Once you have set the date and time you want to search for, highlight the OK
button and press the button. The selected date and time will display. (If no
video was recorded at the selected time, a blank screen will display.) The
Play/Pause, RW, FF, PREV, and Next buttons can now be used to review the
surrounding video.
4.6.3 Calendar Search
Fig. 78 Calendar Search screen.
Days with recorded video display on the calendar with white numbers. You can
highlight the days with recorded video by using the arrow buttons. Once you have
highlighted a day, press the
button to select it.
A time bar will display at the bottom of the calendar. Hours in which video was
recorded will be highlighted. You can use Up and Down arrow buttons to highlight
the time bar. Once the time bar is highlighted, you can select the time by using the
Left and Right arrow buttons.
74
Siemens Building Technologies SISTORE AX9 AX16_EN.doc
Fire & Security Products 09.2004
