Operation
Fig. 74 Preset View screen.
You can save camera position settings as “presets” so that you can go directly to
desired views. Once you have the camera at the desired settings, press the
Search button, and the PTZ Preset dialog box will appear. Select the number you
want to assign to the preset and press the button. Use the virtual keyboard to
enter the preset name. Press the Menu button to load the PTZ preset and the
Preset View dialog box will appear. Select the desired preset and press the
button to load the preset.
4.3 Recording Video
Once you have installed the DVR following the instructions in Chapter 2 —
Installation, it is ready to record.
Although you will be able to record without changing the unit from its original
factory settings, you will want to take advantages of the DVR’s many tools. See
Chapter 3 — Configuration for detailed descriptions of the recording mode options.
NOTE:
The DVR is NOT recording if only the red LED above the REC button is lit. When the DVR is set for
Time-lapse or Event recording, the red LED above the REC button indicates the unit is ready to
record. The red dot appears on the monitor when the clock reaches a scheduled recording time and
the DVR starts recording video.
4.4 Recording Audio
If the DVR was set up to record audio, it will record audio when video is recording.
NOTE:
Make certain you comply with all local and federal laws and regulations when recording audio.
71
Siemens Building Technologies SISTORE AX9 AX16_EN.doc
Fire & Security Products 09.2004
