Appendix F — Recording Table
10 Appendix F — Recording Table
10.1 All 16 Channel Recording Times with 250 GB HDD (Days)
Recording Quality (Standard Resolution)
Recording Speed
Very High (18KB) High (7KB) Standard (3KB) Low (2KB)
60 ips NTSC 2.7 6.9 16.1 24.1
50 ips PAL 3.2 8.3 19.3 28.9
30 ips NTSC 5.4 13.8 32.2 48.2
25 ips PAL 6.4 16.5 38.6 57.9
20 ips 8.0 20.7 48.2 72.3
15 ips 10.7 27.6 64.3 96.5
10 ips 16.1 41.3 96.5 144.7
5 ips 32.2 82.7 192.9 289.4
2.5 ips 64.3 165.3 385.8 578.7
1 ips 160.8 413.4 964.5 1,446.8
0.5 ips 321.5 826.7 1,929.0 2,893.5
0.25 ips 643.0 1,653.4 3,858.0 5,787.0
0.1 ips 1,607.5 4,133.6 9,645.1 14,467.6
Recording Quality (High Resolution)
Recording Speed
Very High (32.4KB) High (12.6KB) Standard (5.4KB) Low (3.6KB)
60 ips NTSC 1.5 3.8 8.9 13.4
50 ips PAL 1.8 4.6 10.7 16.1
30 ips NTSC 3.0 7.7 17.9 26.8
25 ips PAL 3.6 9.2 21.4 32.2
20 ips 4.5 11.5 26.8 40.2
15 ips 6.0
15.3
35.7 53.6
10 ips 8.9 23.0 53.6 80.4
5 ips 17.9 45.9 107.2 160.8
2.5 ips 35.7 91.9 214.3 321.5
1 ips 89.3 229.6 535.8 803.8
0.5 ips 178.6 459.3 1,071.7 1,607.5
0.25 ips 357.2 918.6 2,143.3 3,215.0
0.1 ips 893.1 2,296.4 5,358.4 8,037.6
NOTE:
The ips (images per second) of the above table is not the configured recording speed per camera, but
the total number of recorded images per second. The values of the table represent the average case,
therefore it is not guaranteed.
The SISTORE AX has a maximum recording speed of 50 images for PAL (60 images for NTSC) per
second (ips) that will be applied globally depending on the number of cameras recorded.
86
Siemens Building Technologies SISTORE AX9 AX16_EN.doc
Fire & Security Products 09.2004
