source settling time.)
Test Considerations
⚫ Ensure that the test ambient temperature is stable and between 18°C and
28°C. Ideally the calibration should be performed at 23°C±2°C.
⚫ Ensure ambient relative humidity is less than 80%.
⚫ Allow a 30 minute warm–up period with a copper short connected.
⚫ Ensure the measuring rate is set to “slow” for DCV, ACV, DCI, ACI and
2-Wire/ 4-Wire Resistance measurements.
Zero Offset Verification
Input
Function
Range
Error from Nominal
(1 year)
Open
DC Current
600 μA
±0.03 μA
6 mA
±0.3 μA
60 mA
±3 μA
600 mA
±60 μA
6 A
±500 μA
10 A
±4 mA
Short
DC Volts
600 mV
±60 μV
6 V
±600 μV
60 V
±6 mV
600 V
±60 mV
1000 V
±600 mV
Short
4-wire Ohms
600 Ω
±60 mΩ
6 kΩ
±600 mΩ
60 kΩ
±6 Ω
600 kΩ
±60 Ω
6 MΩ
±300 Ω
60 MΩ
±3 kΩ
100 MΩ
±30 kΩ
