SIGLENT TECHNOLOGIES SDM3045X User Manual

Specifications
DC Characteristics
Accuracy±（% of Reading + count）
[1]
Function
Range
[2]
Test current or
Load voltage
Resolution
Accuracy
（one year；
23℃±5 ℃）
DC Voltage
600 mV
0.01 mV
0.02+ 6
6V
0.0001 V
0.02+ 6
60 V
0.001 V
0.02+ 6
600 V
0.01 V
0.02+ 6
1000 V
[4]
0.1 V
0.02+ 6
DC Current
600 μA
< 33 mV
0.01 μA
0.05+ 3
6 mA
< 330 mV
0.0001 mA
0.05+ 3
60 mA
< 0.05 V
0.001 mA
0.05+ 3
600 mA
< 0.5 V
0.01 mA
0.12+ 6
6 A
< 0.33 V
0.0001 A
0.20+ 5
10 A
[5]
< 0.6 V
0.001 A
0.25+ 4
Resistance
[3]
600 Ω
1 mA
0.01 Ω
0.08+ 6
6 kΩ
1 00 μA
0.0001 kΩ
0.04+ 6
60 kΩ
10 μA
0.001 kΩ
0.04+ 6
600 kΩ
1 μA
0.01 kΩ
0.08+ 6
6 MΩ
200 nA
0.0001 MΩ
0.12+ 3
60 MΩ
200 nA || 10 MΩ
0.001 MΩ
0.85+ 3
100 MΩ
200 nA || 10 MΩ
0.01 MΩ
1.75+ 3
Diode Test
[6]
0～2V
1 mA
0.0001 V
0.05+ 3
2～4V
1 mA
0.0001 V
0.35+ 3
Continuity Test
2000 Ω
1 mA
0.1 Ω
0.05+ 3
Remarks:
[1] Specifications are for 0.5 Hour warm-up, “Slow” measurement rate and calibration
temperature 18℃～28℃.
[2]10% over range on all ranges except for DCV 1000 V, ACV 750 V, DCI 10 A and ACI 10
A.
[3] Specifications are for 4-wire measure or 2-wire measure under “REF” operation.±0.2Ω
of extra errors will be generated if perform 2-wire measure without “REF” operation.
[4] Plus 0.02 mV of error per 1 V after the first ±500 VDC.
[5] 30 seconds OFF after 30 seconds ON is recommend foe the continuous current that
higher than DC 7 A or AC RMS 7 A.
[6] Accuracy specifications are only for voltage measuring at input terminal. The typical
value of current under measure is 1 mA. Voltage drop at diode junction may vary with
current supply. Adjustable voltage range ：0~4 V.
