SIGLENT TECHNOLOGIES SDM3045X - AC Characteristics

SDM3045X Service Manual 3
AC Characteristics
Accuracy ±（% of Reading + count）
[1]
Function
Range
[2]
Frequency
Range
Resolution
Accuracy
（one year；
23℃±5 ℃）
True-RMS
AC Voltage
[3]
600 mV
20 Hz – 45 Hz
0.01 mV
2.0 + 20
45Hz – 100 Hz
0.01 mV
0.6 +10
100 Hz – 20 kHz
0.01 mV
0.3 + 20
20 kHz – 50 kHz
0.01 mV
2.0 + 40
50kHz –100 kHz
0.01 mV
3.0 + 10
6V
20 Hz – 45 Hz
0.0001 V
2.0 + 20
45Hz – 100Hz
0.0001 V
0.6 + 10
100 Hz – 20 kHz
0.0001 V
0.8 + 20
20 kHz – 50 kHz
0.0001 V
2.0 + 40
50 kHz –100 kHz
0.0001 V
3.0 + 40
60 V
20 Hz – 45 Hz
0.001 V
2.0 + 20
45 Hz – 100 Hz
0.001 V
0.6 +10
100 Hz – 20 kHz
0.001 V
0.8 + 20
20 kHz – 50 kHz
0.001 V
2.0 + 40
50 kHz –100 kHz
0.001 V
3.0 + 40
600 V
20 Hz – 45 Hz
0.01 V
2.0 + 20
45 Hz – 100 Hz
0.01 V
0.6 + 10
100 Hz – 20 kHz
0.01 V
0.8 + 20
20 kHz – 50 kHz
0.01 V
2.0 + 40
50 kHz –100 kHz
0.01 V
3.0 + 40
750 V
20 Hz – 45 Hz
0.01 V
2.0 + 20
45 Hz – 100 Hz
[4]
0.01 V
0.6 + 10
100 Hz – 20 kHz
0.01 V
0.8 + 20
20 kHz – 50 kHz
0.01 V
2.0 + 40
50 kHz –100 kHz
0.01 V
3.0 + 40
True-RMS
AC Current
[5]
60 mA
20 Hz – 45 Hz
0.001 mA
2.0 + 20
45 Hz – 2 kHz
0.001 mA
0.5 + 20
2 kHz – 10 kHz
0.001 mA
2.5 + 30
600 mA
20 Hz – 45 Hz
0.01 mA
2.0 + 20
45 Hz – 2 kHz
0.01 mA
0.5 + 20
2 kHz – 10 kHz
0.01 mA
2.5 + 30
6 A
20 Hz – 45 Hz
0.0001 A
2.0 + 20
45 Hz – 2 kHz
0.0001 A
0.5 + 20
2 kHz – 10 kHz
0.0001 A
2.5 + 20
10 A
[6]
20 Hz – 45 Hz
0.001 A
1.5 + 45
45 Hz – 2 kHz
0.001 A
0.5 + 35
