SIGLENT
8 SPD3000X QuickStart
The rear panel
○
1 warning message
○
2 The DIP switch of the AC power and its identification.
○
3 The description of the AC input voltage
○
4 AC power socket
○
5 The fan air vents
○
6 CE certification mark
○
7 USB interface and identification
○
8 LAN interface and identification
○
9 TÜ V certification mark
○
1
○
2
○
6
○
5
○
4
○
3
○
7
○
8
○
9
