SIGLENT
SPD3000X QuickStart 11
2.1 Output summary
SPD3303X/3303X-E have three independent outputs, two of which are
adjustable in voltage value and the other one includes selectable 2.5V, 3.3V or
5.0V
Independent/Parallel/Series
SPD3303X/3303X-E have three output modes: independent、parallel and
series, which can be selected through the track switch on the front panel. In
the independent mode, the output current and voltage are controlled
respectively. In the parallel mode, the current value is twice that of the single
channel. In the series mode, the voltage value is twice that of the single
channel.
Constant voltage/current
In the constant current mode (independent or tracking mode), the current value
is rated and controlled through the front panel. The indicator light displays red
and the voltage value is under rating. It will return to constant voltage mode
when the current value is under dating.
In the constant voltage mode, the current value is less than the setting value,
and the voltage value is controlled through the front panel. The indicator light
displays yellow and the current value is maintained at the set value. It will
return to constant current mode when the voltage value is under dating.
