SIGLENT
12 SPD3000X QuickStart
2.2 CH1/CH2 Independent Output
Instruction
CH1 and CH2 are working in the independent mode, at the same time，they
are insulated from the ground.
Output rating 0~32V/0~3.2A
Operation steps
1. Make sure that parallel/series mode is off.
2. Connect load to the positive and negative terminals of CH1/CH2.
3. Set voltage and current value of CH1/CH2:
a) Press “1”/”2” button to select the wanted channel
b) Move the cursor through direction button to select the wanted
parameter(voltage, current),
c) Press “Fine” to select the digit position and then revolve the
multi-function knob to change the corresponding parameter.
4. turn on the output ：
Press “on/off” button to turn on the output, the corresponding indicator light
gets lighted immediately and “CC” or “CV” is showed on the current
interface.
