SIGMATEK C-DIAS User Manual

C-DIAS PROCESSOR MODULE CCP 611
27.03.2020 Page 13
4.1 Applicable Connectors
Connectors
Type
Wire Size
Max. Tightening Torque
X2
USB Type A
-
-
X3, X4
RJ 45
-
-
X5
B2L 3.5/6
0.13 - 1.0 mm
2
28 - 18 AWG (UL/CSA)
Spring terminal
X1
USB Type Mini-B
-
-
X6
FK-MCP 1.5/ 2-ST-3.5
0.14 - 1.5 mm
2
28 - 16 AWG (UL/cUL)
Spring terminal
MC 1.5/ 2-ST-3.5
0.13 - 1.0 mm
2
,
30 - 16 AWG (UL),
28 - 16 AWG (CSA)
0.22 - 0.25 Nm
Applicable Connectors
USB Device: 5-pin, type Mini-B
USB Host: 4-pin, type A
Ethernet: 8-pin RJ45
VARAN: 8-pin, RJ45
CAN Bus: 6-pin Weidmüller plug, B2L3, 5/6
Supply: 2-pin Phoenix plug with screw terminal technology MC 1.5/ 2-ST-3.5
2-pin Phoenix plug with spring terminal FK-MCP 1.5/ 2-ST-3.5
The complete C-DIAS CKL 031 connector set with spring terminals is available from
SIGMATEK under the article number 12-600-017.
