SIGMATEK C-DIAS User Manual

CCP 611 C-DIAS PROSESSOR MODULE
Page 4 27.03.2020
18.4 Connecting Noise Generating Components ............................ 41
18.5 Shielding Between Two Control Cabinets ............................... 42
1 Technical Data
1.1 Performance Data
Processor
EDGE Technology X86 compatible
32-bit data bus
Clock frequency
800 MHz
Addressable I/O/P modules
VARAN bus: 65,280
CAN bus: 32
C-DIAS bus: 8
Internal I/O
no
Internal cache
32-kbyte L1 Cache
256-kbyte L2 cache
BIOS
AMI
Internal program and data memory
(DDR2 RAM)
128-Mbyte
Internal remnant data memory
512-kbyte
(1)
Internal storage device
512-Mbyte microSD card
Interfaces
1x USB Host 2.0 (full speed 12 Mbit/s)
1x USB Device 1.1
1x Ethernet
1x CAN
1x VARAN Out (Manager) (maximum cable length: 100 m)
1x C-DIAS
Data buffer
yes
Status display
yes
Status LEDs
yes
Real-time clock
yes (buffering approximately 10 days)
(1)
See chapter “Note on SRAM Behavior”
