The test is fiber passing
Fiber passing means screen display is a complete fiber, take out fiber can be normal.
Sometimes errors may be reported due to dirty lens or fog, and the lens can be restored after cleaning (see
daily maintenance for specific operations).
Failed to identify qualified optical fiber or no optical fiber detected
A Red Cross is displayed on the v-slot mark to indicate that no fiber has been identified or no fiber has been
laid.
If the optical fiber has been placed, and the error is still reported, firstly exclude the unqualified factors of
the optical fiber treatment, such as the coating layer is not clean, the cutting surface is too bad, too many
burrs, etc.; Then clean up the V groove and objective lens, and press the reset key (see daily maintenance
for specific operations).
Blurry fiber images can also cause errors,clear V slot and objective lens, press reset key;In addition, the
reasons for the unclear fiber image include wrong focal length and lighting problems. (Please refer to daily
maintenance for details.)
In rare cases, there is a signal or light source in the fiber optic line, which may affect the image detection of
welding machine and cause error reporting. Turn off the signal or light source in the circuit.
INTRODUCTION TO SPLICE INTERFACE
15
CHAPTER II SOFTWARE DOWNLOAD
16
Software download
China: scan QR code to download APP
Outside China: Go to Google Play or App Store and search for"Signalfire2 “download
Phone App.
Google play
App store
Scan QR code
To Next Page
