SIGNAL FIRE AI-9 User Manual

Safety Requirements
Warnings/precautions
Chapter I
Operation Keys And Parts Introduction
Display Menu Introduction
Introduction To Splice Interface
Chapter II
Software Download
Software Bluetooth Connection
Screen Menu Function On/off
Chapter III Smart Lock
Chapter IV Toolbox Introduction
Chapter V Arc Calibration
Chapter VI Fiber Stripping And Put Into Holder
Chapter VII Replace Electrode
Chapter VIII Activate Electrode
Chapter IX Power Meter And Optical Modules
Chapter XI Daily Maintenance
Chapter XII Lighting And Power Supply
01
02
05
09
10
16
17
19
22
24
25
26
27
29
31
33
43
CATALOGUE

SIGNAL FIRE AI-9 Specifications

General

Category	Fusion Splicer
Fiber Alignment	Core Alignment
Cutting Length	8-16mm
Interface	USB
Communication Interface	USB
Applicable Fibers	SM, MM, DS, NZDS
Splice Loss	0.02dB (SM)
Return Loss	>60dB
Typical Splice Time	9 seconds
Fiber Diameter	80-150μm
Power Supply	AC 100-240V
Monitor Fiber View	4.3 inch LCD
Operating Condition	-10°C to 50°C
Storage Condition	Humidity: 0-95%, Temperature: -20℃~+75℃
