SIGNAL FIRE AI-9 User Manual

SMART LOCK
23
CHAPTER IV TOOLBOX INTRODUCTION
24
A Device Can Only Be Bound To One Mobile Account At The Same Time. To Bind Other Mobile Phones.
You Need To Unbind Current Account First.
3. Click on the settings icon to
enter.
4. Save after personalization
settings.
5. Click on the"Smart lock
management "button to see
all the splicing machines
controlled by this mobile
phone account.
Lock catch
Tool layer
Platform for fiber cleaving
Accessory layer
Stool

SIGNAL FIRE AI-9 Specifications

General

Category	Fusion Splicer
Fiber Alignment	Core Alignment
Cutting Length	8-16mm
Interface	USB
Communication Interface	USB
Applicable Fibers	SM, MM, DS, NZDS
Splice Loss	0.02dB (SM)
Return Loss	>60dB
Typical Splice Time	9 seconds
Fiber Diameter	80-150μm
Power Supply	AC 100-240V
Monitor Fiber View	4.3 inch LCD
Operating Condition	-10°C to 50°C
Storage Condition	Humidity: 0-95%, Temperature: -20℃~+75℃
