Signode BXT2-19 - Technical Data

6
10.13
SIGNODE BXT2-19
1 TECHNICAL DATA
Weight 4.2 kg (9.3 lbs.)
(incl. battery)
Dimensions Length 370 mm (14.5“)
Width 138 mm (5.4“)
Height 148 mm (5.8“)
Strap tension (0) 1200–4000 N (264–882 lbs.)
Soft: 400–1600 N (88–353 lbs.)
Tension speed 175 mm/s (6.9“/s)
Sealing Friction weld
Emission sound pressure
levels, measurement
type A (EN ISO 11202) L
pA
79 dB (A)
Vibrations at handle
(EN ISO 8662-1) a
h,w
2.2 ms
-2
Workingtemperature –10°Cupto+40°C
 (14°Fupto104°F)
Relative humidity Up to 90 %
BATTERY CHARGER / BATTERY
Battery charger voltage 100 / 110 / 230 V
Battery charger type BOSCH AL 1860 CV
Charging time 15–30 minutes,
after 15 min. approx. 75%
charging capacity
Strappings with
one battery charge 180 to 300 depending on
strap, strap tension and
package
Battery 18 V / 2.6 Ah, Li-Ion
BOSCH
PLASTIC STRAP
Strap quality Polypropylene (PP)
Polyester (PET)
Strap width
adjustable to 16–19 mm
(
5
/
8
“–
3
/
4
“)
Strap thickness 0.8–1.3 mm (.030“–.051“)
