AG25
Identification English
AG25 · Date 19.07.2022 · Art. No. 87450 · Mod. status 157/22
28
3 Identification
Please check the particular type of unit and type number from the identifi-
cation plate. Type number and the corresponding version are indicated in
the delivery documentation.
e. g. AG25-0023
version number
type of unit
4 Installation
Actuator failure/damage to the connector insert
The connector insert in the device will be damaged if the torque applied to
the mating connector is too high.
` Tighten the mating connector using the torque-limiting wrench of
the relevant connector vendor. Pay attention to the tightening torque
specified by the manufacturer.
` Using a torque wrench tighten the mating connector (see chapter 8.1,
8.2 and 8.3). Manufacturer's recommendation of a suitable torque can
be obtained on request.
Tightening torque: 0.6Nm (M12)
` Do not transmit torque/forces into the device via the housing of the
mating connector or cable. Tighten only the securing nut of the mat-
ing connector.
Loss of type of connection/shielding
If the torque of the mating connector is too low this will result in loss of
type of protection and/or shielding.
` Tighten the mating connector using the torque-limiting wrench of
the relevant connector vendor. Pay attention to the tightening torque
specified by the manufacturer.
` Using a torque wrench tighten the mating connector (see chapter 8.1,
8.2 and 8.3). Manufacturer's recommendation of a suitable torque can
be obtained on request.
Tightening torque: 0.6Nm (M12)
If the use of the torque-limiting wrench is not possible due to the mount-
ing situation, execute electrical installation before mechanical installa-
tion.
WARNING
NOTICE
