Siko AG25 Translation Of The Original Installation Instructions

AG25
Technical data English
AG25 · Date 19.07.2022 · Art. No. 87450 · Mod. status 157/22
43
9 Technical data
Mechanical data Additional information
Shaft stainless special steel
Housing plastic glass-fibre reinforced
and Zinc diecasting / powder-
coated
Clamping ring stainless special steel
Torque support stainless steel form A
stainless steel form B
Nominal torque/rated
speed
5Nm at 50min
-1
±10% i=98
3Nm at 75min
-1
±10% i=66
Operating mode duty type S3: 25% ED,
10min.
EN 60034-1
Weight ~0.8kg
Electrical data Additional information
Operating voltage 24VDC ±10% polarity protection, output
stage
24VDC ±10% polarity protection, control
Current consumption 2.2A ±10% at max. admissable torque (out-
put stage)
<150mA Starting current >150 mA (con-
trol)
Power input ≤58W output stage
Notes on UL approval:
The device shall be supplied
from an isolated source with a
secondary overcurrent protec-
tion 24VDC, max. 4A. Alterna-
tively the device can be supplied
from a Class 2 (UL 1310) source.
≤3.6W control
Notes on UL approval:
The device shall be supplied
from an isolated source with a
secondary overcurrent protec-
tion 24VDC, max. 4A. Alterna-
tively the device can be supplied
from a Class 2 (UL 1310) source.
Battery CR2477N, 3V lithium,
950mAh
Battery service life ~5 years depending on ambient condi-
tions
