8.2 Mating connector M12 straight inclusive cable
• Accessory SIKO art. no. "KV04S2" (socket contact connector 4 poles).
• Accessory SIKO art. no. "KV08S2" (socket contact connector 8 poles).
8.3 Right angle mating connector M12
Advice
` Strand cross-section of lines 0.75mm² / cable feed-through: ø4 ...
ø8mm.
• Accessory SIKO art. no. "83091" M12 A coded (socket contact 4 poles
operating voltage).
• Accessory SIKO art. no. "87599" M12 A coded (socket contact 8 poles
digital input / output).
• Accessory SIKO art. no. "87600" M12 D coded (socket contact 4 poles
Port1 + Port2).
Mounting (Fig. 16)
1. Slide the pressure nut and housing along the cable.
2. Strip the cable, shorten the screen.
3. Strip wires and connect.
4. Screw housing with insert.
5. Tighten pressure nut.
Fig. 16: Right angle mating connector M12
8
3
1
1
2
Changing the angle position (Fig. 16)
1. Turn on insert, slightly pull out and rotate to desired angular position
(in steps of 45°).
2. Screw on insert.
NOTICE
