Technical data English
AG25 · Date 19.07.2022 · Art. No. 87450 · Mod. status 157/22
44
Electrical data Additional information
Parameter memory 10
6
cycles also applies to calibration pro-
cedures
Digital input 17 ... 30 V DC typical 10 mA
Status display 8 LEDs function description (see user
manual)
Keys 2 internal keys, internal DIP
switch
Digital inputs 24 V DC ±10 % ≤40 mA (high-side)
Bus connection EIP-EtherNet/IP
EPN-PROFINET
ECT-EtherCAT
EPL-POWERLINK
Typ of connection 2x M12 connector (A coded) 4 poles, 1x pin; 8x poles, 1x pin
2x M12 connector (D coded) 4 poles, 2x socket
earthing by contact pin
6.3mm
System data Additional information
Resolution 720 increments/revolution
shaft
Repeat accuracy ±1 increment(s)
Travel range ±1300 revolution(s) i=98
±1980 revolution(s) i=66
Failure rate 28.3 year(s) at 60° C (MTBF) according to
SN29500
Approval UL UL 2011, CSA C22.2 No. 14-18,
File Nr. E502992
Ambient conditions Additional information
Ambient temperature 0 ... 45°C
Storage temperature -20 ... 60°C
Relative humidity condensation not permitted
EMC EN 61800-3, second environ-
ment
interference resistance / immis-
sion
EN 61800-3, C2 emitted interference / emission
Protection category IP54, IP65 EN 60529, only with mating con-
nectors (Protection category not
tested by UL)
Shock resistance 500m/s
2
, 11ms EN 60068-2-27
Vibration resistance ≤100m/s
2
, 5 … 150 Hz EN 60068-2-6
