For a description of the functions of the drive status LEDs refer to the rele-
vant user manual.
Status LED 5
LED statuses valid with factory settings.
LED status Description
green Operating voltage applied to control, no fault
red, blinks Operating voltage applied to control, fault active
o Operating voltage of control missing
Status LED 6, 7
LED statuses valid with factory settings.
LED status Description
o no Function
Status LED 8
If the actual value is unequal after switching on the module and if it is out-
side the programmed positioning window, then the LED status is “red” or
“red, flashing” due to volatile storage of the setpoint. The setpoint is ini-
tialized with the value 0 after switching on.
LED statuses valid with factory settings.
LED status Description
green Actuator is within the programmed position
window. Supply voltage of the output stage is
applied.
green, blinks Actuator is within the programmed position
window. Supply voltage of the output stage missing.
red Actuator is outside the programmed position
window. Supply voltage of the output stage is
applied.
red, blinks Actuator is outside the programmed position
window. Supply voltage of the output stage missing.
o Operating voltage of control missing.
