AP04
Documentation English
AP04 · Date 19.05.2016 · Art. No. 84211 · Mod. status 154/16
22
1 Documentation
The following documents describe this product:
• The data sheet describes the technical data, the dimensions, the pin
assignments, the accessories and the order key.
• The mounting instructions describe the mechanical and electrical
installation including all safety-relevant requirements and the associ-
ated technical specifications.
• The user manual and software description for commissioning and inte-
grating the position indicator into a fieldbus system.
These documents can also be downloaded at "http://www.siko-global.
com/p/ap04".
2 Safety information
2.1 Intended use
The AP04 position indicator serves for adjustment and positioning tasks
on plants and machines. The position indicator is only intended for use in
industrial applications that are not subject to special electrical or mecha-
nical safety requirements.
1. Observe all safety instructions contained herein.
2. Arbitrary modifications and changes to this position indicator are for-
bidden.
3. Observe the prescribed operating and installation conditions.
4. Operate the position indicator exclusively within the technical data
and the specified limits (see chapter 9).
2.2 Identification of dangers and notes
Safety notes consist of the signal symbol and a signal word.
Danger classes
Immediate danger that may cause irreversible bodily harm resulting in
death, property damage or unplanned device reactions if you disregard
the instructions given.
Danger that may cause serious bodily harm, property damage or
unplanned device reactions if you disregard the instructions given.
DANGER
WARNING
