AP04
Battery change English
AP04 · Date 19.05.2016 · Art. No. 84211 · Mod. status 154/16
33
At the time of delivery, the AP04 is fully functioning and no alignment
travel is required. The absolute position value can get lost if both bat-
tery supply and supply voltage fail at the same time (when the battery is
exchanged for example). Zeroing must be executed to restore functional
capability.
The following procedure must be followed if alignment travel is to be per-
formed nevertheless: The AP04 is moved to the calibration mode by ente-
ring CODE 00100 after having acknowledged the display direction.
Display: 1st line "AbGL_"
2nd line "_XXX" with XXX displaying a value around 100.
Now, the AP04 shaft must be rotated ccw by a few mm, with a velocity of
<1U/min. The value in the lower line changes in positive direction up to
"103". The calibration process is completed when this value has been last
exceeded. The AP04 is in normal operation or pre-operational mode again
and shows the respective display.
It is not uncommon that the position value will not be displayed immedia-
tely after calibration travel and "FULL" displayed instead of the value. In
this case, the display should be zeroed.
6 Battery change
Inflammable, danger of explosion and burns
` Do not recharge the battery nor expose it to temperatures above
85°C.
` Dispose of used batteries properly.
Danger of short circuit
` Do not insert sharp or metallic objects into the inside of the housing
in case of remote battery compartment.
Loss of data
With missing supply voltage and empty or missing battery, calibration of
the sensor unit will be lost.
` It is mandatory to change the battery with supply voltage switched on.
` Repeated calibration travel in case of data loss (refer to the see User
manual for the procedure).
DANGER
CAUTION
CAUTION
