6.5 Replacing the fuses
ATTENTION: disconnect the power lead from the mains and machine.
1) Remove the fuses box from the key-cutting machine socket (R) (Fig.33).
2) Replace the fuses (R1).
3) Close the fuses box and connect the power cable.
ATTENTION: fuses must always be replaced with others of the same type and with the same
Amps (4 Amp rapid for 230V - 8 Amp rapid for 120V).
Fig.33
6.6 Access to the lower compartment
ATTENTION: remove the mains plug.
1) Detach the wire from the key-cutting machine socket.
2) Remove the swarf tray (L) (Fig.34).
3) Paying attention turn the machine slowly onto its back.
4) Loosen the 3 screws (W1) and remove the plate (W) (Fig.35).
Fig.34 Fig.35
