5 CUTTING OPERATIONS
ATTENTION: for complete safety during the cutting operations, take the following precautions:
• Always work with dry hands.
• Check that the machine is properly earthed.
• Wear protective goggles even if the machine has a protective shield over the cutting tool.
• Start the motor (switch K) only after completing the operations on the carriage (securing the keys,
etc..).
• Keep hands away from the cutting tool in motion.
• Before duplicating, remove the gauges.
5.1 Key cutting
Standard only on
120V version
Fig.18
Place the clamps on the required side (see chap.5.1.1):
- Side A of the clamp: for keys to be tted on their backs, keys with double cuts without groove and cruciform
keys (Fig.19 - Fig.20);
- Side B of the clamp: for keys placed on their backs and having cuts with a depth of less than 3,9 mm (Fig.19
- Fig.20);
- Side C and D of the clamp: for keys to be cut on both sides and locked on the groove (Fig.19 - Fig.20).
