Silca Speed - Terminology and Visual Guides; Understanding Manual and Machine Symbols

TERMINOLOGY
For those inexperienced in the subject of keys and key cutting, below is an illustration of the most frequently used
terms:
Standard only on
120V version
Fig.2
1) Head
2) Neck
3) Stop
4) Blade
5) Tip
6) Back
7) Cuts
8) Stem
GRAPHICS IN THE USER’S MANUAL
Pay attention Obligation to read the manual
GRAPHICS ON THE SPEED MACHINE
Obligatory use of safety goggles
Read instructions
before use
WARNING!
cutting tool in motion
WARNING!
presence of electric power
Earth connection Cutter rotation direction
Operating manual SPEED
