Silicon Graphics GDM-5411 User Manual

GDM-5411
2-1. CABINET REMOVAL
SECTION 2
DISASSEMBLY
2-2. D BOARD REMOVAL
2-1
Top cover
Video shield
5
7
3
2
1
Two claws
2
Two claws
Bezel assembly Bezel assembly
Cabinet
Cabinet
Cabinet
Four screws
(+ BVTT 4 x 8)
6
Four screws
(+ BVTT 4 x 8)
4
Two screws
(+ BVTP 4 x 16)
Push in the tip of a screwdriver
about 5mm to unlock the claw.
Two screws
(+ BVTT 4 x 8)
Two screws
(+ BVTP 3 x 12)
D board
Screw
(+ P 3.5 x 20)
Open the D block in the direction
of the arrow . and remove of
the arrow .
Two hooks
5
A
B
A
B
CN504
CN505
GND
1
2
3 4
