GDM-5411

– 4 –

MODE AT PRODUCTION MODE8 MODE9 MODE10 MODE11 MODE12 MODE13

RESOLUTION 1280 X 1024 1280 X 1024 1280 X 1024 1600 X 1024 1600 X 1200 1920 X 1035

CLOCK 129.250 MHz 135.000 MHz 140.250 MHz 158.400 MHz 229.500 MHz 159.923 MHz

— HORIZONTAL —

H-FREQ 76.935 kHz 79.976 kHz 81.922 kHz 77.647 kHz 106.250 kHz 65.009 kHz

usec usec usec usec usec usec

H. TOTAL 12.998 12.504 Hz 12.207 12.879 9.412 15.382

H. BLK 3.095 3.022 3.080 2.778 2.440 3.377

H. FP 0.248 0.119 0.228 0.303 0.279 0.275

H. SYNC 1.083 1.067 1.255 0.909 0.837 0.825

H. BP 1.764 1.837 1.597 1.566 1.325 2.276

H. ACTIV 9.903 9.481 9.127 10.101 6.972 12.006

— VERTICAL —

V. FREQ(HZ) 72.239 Hz 75.025 Hz 75.924 Hz 72.029 Hz 85.000 Hz 60.194 Hz

lines lines lines lines lines lines

V. TOTAL 1065 1066 1079 1078 1250 1080

V. BLK 41 42 55 54 50 45

V. FP 3 1 3 3 1 3

V. SYNC 3 3 3 3 3 10

V. BP 35 38 49 48 46 32

V. ACTIV 1024 1024 1024 1024 1200 1035

— SYNC —

INT(G) YES NO YES YES NO YES

EXT(H/V)/POLARITY NO YES P/P NO NO YES P/P NO

EXT(CS) /POLARITY NO NO NO NO NO NO

INT/NON INT NON INT NON INT NON INT NON INT NON INT NON INT

TIMING SPECIFICATION

MODE AT PRODUCTION MODE1 MODE2 MODE3 MODE4 MODE5 MODE6 MODE7

RESOLUTION 800 X 600 1024 X 768 1024 X 768 1024 X 768 1280 X 492 1280 X 1024 1280 X 1024

CLOCK 81.000 MHz 63.546 MHz 103.503 MHz 135.000 MHz 107.250 MHz 89.571 MHz 107.250 MHz

— HORIZONTAL —

H-FREQ 76.705 kHz 48.732 kHz 77.472 kHz 96.983 kHz 63.893 kHz 53.316 kHz 63.839 kHz

usec usec usec usec usec usec usec

H. TOTAL 13.037 20.521 12.908 10.311 15.664 18.756 15.664

H. BLK 3.160 4.406 3.014 2.726 3.730 4.466 3.730

H. FP 0.296 1.133 0.251 0.119 0.373 0.357 0.373

H. SYNC 0.988 1.196 1.005 1.067 1.119 1.340 1.119

H. BP 1.877 2.077 1.758 1.541 2.238 2.769 2.238

H. ACTIV 9.877 16.114 9.893 7.585 11.935 14.290 11.935

— VERTICAL —

V. FREQ(HZ) 119.851 Hz 59.940 Hz 96.000 Hz 119.880 Hz 119.999 Hz 50.062 Hz 59.943 Hz

lines lines lines lines lines lines lines

V. TOTAL 640 813 807 809 532 1065 1065

V. BLK 40 45 39 41 40 41 41

V. FP 1 3 3 1 3 3 3

V. SYNC 3 3 3 3 3 3 3

V. BP 36 39 33 37 34 35 35

V. ACTIV 600 768 768 768 492 1024 1024

— SYNC —

INT(G) YES YES NO NO YES YES YES

EXT(H/V)/POLARITY NO NO YES N/N YES P/P NO NO NO

EXT(CS) /POLARITY NO NO NO NO NO NO NO

INT/NON INT NON INT NON INT NON INT NON INT NON INT NON INT NON INT

99.11.04 VER.
