Silicon Graphics GDM-5411 User Manual

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
GDM-5411
7-1
The components identified ¡ marked are
critical for safety.
Replace only with the part number specified.
Les composants identifiés par la marque ¡
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
NOTE:
When indicating parts by reference
number, please include the board name.
REF.NO. PART NO. DESCRIPTION REMARK
SECTION 7
ELECTRICAL PARTS LIST
REF.NO. PART NO. DESCRIPTION REMARK
The components identified by [ in this
manual have been carefully factory-
selected for each set in order to satisfy
regulations regarding X-ray radiation.
Should replacement be required, replace
only with the value originally used.
• All variable and adjustable resistors have
characteristic curve B, unless otherwise
noted.
(a)
• Items marked " * " are not stocked since
they are seldom required for routine
service. Some delay should be anticipated
when ordering these items.
RESISTORS
• All resistors are in ohms
• F : nonflammable
* A-1298-874-EA BOARD, COMPLETE
***************************
7-682-950-01 SCREW +PSW 3X12 (IC403)
<CAPACITOR>
C101 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C102 1-104-664-11 ELECT 47µF 20% 25V
C103 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C104 1-104-664-11 ELECT 47µF 20% 25V
C107 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C108 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C109 1-163-229-11 CERAMIC CHIP 12pF 5% 50V
C110 1-163-275-11 CERAMIC CHIP 0.001µF 5% 50V
C112 1-164-489-11 CERAMIC CHIP 0.22µF 10% 16V
C113 1-164-489-11 CERAMIC CHIP 0.22µF 10% 16V
C114 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C115 1-104-341-11 FILM 0.1µF 10% 250V
C120 1-104-341-11 FILM 0.1µF 10% 250V
C201 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C202 1-104-664-11 ELECT 47µF 20% 25V
C203 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C204 1-104-664-11 ELECT 47µF 20% 25V
C205 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C206 1-109-982-11 CERAMIC CHIP 1µF 10% 10V
C207 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C208 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C209 1-163-227-11 CERAMIC CHIP 10pF 0.5pF 50V
C210 1-163-275-11 CERAMIC CHIP 0.001µF 5% 50V
C212 1-164-489-11 CERAMIC CHIP 0.22µF 10% 16V
C213 1-164-489-11 CERAMIC CHIP 0.22µF 10% 16V
C214 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C215 1-104-341-11 FILM 0.1µF 10% 250V
C216 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C220 1-104-341-11 FILM 0.1µF 10% 250V
C301 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C302 1-104-664-11 ELECT 47µF 20% 25V
C303 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C304 1-104-664-11 ELECT 47µF 20% 25V
C307 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C308 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C309 1-163-227-11 CERAMIC CHIP 10pF 0.5pF 50V
C310 1-163-275-11 CERAMIC CHIP 0.001µF 5% 50V
C312 1-164-489-11 CERAMIC CHIP 0.22µF 10% 16V
C313 1-164-489-11 CERAMIC CHIP 0.22µF 10% 16V
C314 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C315 1-104-341-11 FILM 0.1µF 10% 250V
C320 1-104-341-11 FILM 0.1µF 10% 250V
C401 1-126-964-11 ELECT 10µF 20% 50V
C402 1-104-664-11 ELECT 47µF 20% 25V
C403 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C404 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C405 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C406 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C407 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C408 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C410 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C411 1-126-934-11 ELECT 220µF 20% 16V
C413 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C415 1-164-489-11 CERAMIC CHIP 0.22µF 10% 16V
C416 1-126-961-11 ELECT 2.2µF 20% 50V
C417 1-104-574-11 CERAMIC 0.0047µF 10% 2KV
C419 1-162-318-11 CERAMIC 0.001µF 10% 500V
C420 1-164-489-11 CERAMIC CHIP 0.22µF 10% 16V
C421 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C422 1-164-489-11 CERAMIC CHIP 0.22µF 10% 16V
C423 1-104-664-11 ELECT 47µF 20% 25V
C424 1-162-318-11 CERAMIC 0.001µF 10% 500V
C425 1-163-251-11 CERAMIC CHIP 100pF 5% 50V
C426 1-163-251-11 CERAMIC CHIP 100pF 5% 50V
C427 1-163-235-11 CERAMIC CHIP 22pF 5% 50V
C430 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C431 1-163-275-11 CERAMIC CHIP 0.001µF 5% 50V
C432 1-164-489-11 CERAMIC CHIP 0.22µF 10% 16V
C433 1-162-318-11 CERAMIC 0.001µF 10% 500V
C434 1-162-318-11 CERAMIC 0.001µF 10% 500V
C435 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C436 1-164-489-11 CERAMIC CHIP 0.22µF 10% 16V
C437 1-126-935-11 ELECT 470µF 20% 16V
C438 1-115-339-11 CERAMIC CHIP 0.1µF 10% 50V
C440 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C441 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C442 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C443 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C444 1-162-318-11 CERAMIC 0.001µF 10% 500V
The components identified ¡ marked are
critical for safety.
Replace only with the part number specified.
Les composants identifiés par la marque ¡
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
